JCB strimmer instructions
Petrol-driven string trimmers make grass and weed trimming easy. (Jupiterimages/Photos.com/Getty Images)

String trimmers, also known as strimmers, use a length of monofilament line rotated at high speed to trim grass, weeds and other growth. The JCB BC-26 is a string trimmer powered by a 26cc, .9 horsepower two-stroke petrol engine. It operates at 2,800rpm at idle and 10,000rpm at maximum speed. The BC-26 uses 2.4mm or 2.8mm (15/64 or 9/32 inch) monofilament trimming line and cuts an 45 cm (18 inch) swath. The fuel tank holds 0.25 litres (0.44 pints) of petrol/oil mixture and the BC-26 weighs 4.54 kg (10 lbs).

Skill level:
Easy

Other People Are Reading

Instructions

    Fuel mixing

  1. 1

    Shut off the engine and allow it to cool before fuelling.

  2. 2

    Mix a 50-to-1 ratio of 91 octane or higher petrol with synthetic two-stroke oil.

  3. 3

    Clean the area around the fuel filler cap of leaves and dirt and remove the cap. Fill the tank and replace the fuel cap.

    Starting the engine

  1. 1

    Lay the trimmer down on a flat surface. Turn the On/Off switch on the engine to "On."

  2. 2

    Push in on the clear fuel primer bulb 10 times. Fuel should be visible in the bulb.

  3. 3

    Move the choke lever on the engine to the "Full" setting.

  4. 4

    Open the throttle completely by squeezing the throttle lever to its limit.

  5. 5

    Pull the starter cord until the engine starts.

  6. 6

    Let the engine warm up for 10 seconds and move the choke lever on the engine to the "Run" setting.

  7. 7

    Stop the engine by pressing and holding the On/Off switch in the "Off" position until the engine stops.

    Trimmer operation

  1. 1

    Grasp the trimmer by the rear handle with one hand and the front handle with the other hand. The rear handle should be held at approximately hip height.

  2. 2

    Operate the trimmer at full throttle at all times.

  3. 3

    Keep the cutting head parallel with the ground at a slightly slanted angle. Move the head from left to right in steady strokes.

  4. 4

    Trim tall grass and weeds beginning at the top of the growth, cutting down to the desired height.

    String replacement

  1. 1

    Turn off the engine and disconnect the spark plug wire.

  2. 2

    Pull the old line out of the holes on top of the string head.

  3. 3

    Use two pre-cut strimmer lines or cut two pieces of strimmer line 27.5 cm (11 inches) in length.

  4. 4

    Insert the lengths of strimmer line into the two slots located on the side of the strimmer head.

  5. 5

    Push the line in until about one inch protrudes from the holes on top of the string head.

  6. 6

    Reconnect the spark plug wire.
