The Honda EX650 is a portable generator, suitable for camping or for running appliances during a power outage. Its sturdy handle and relatively light weight (23.1 Kilogram) makes it easy to carry with one hand, and the motor is fully enclosed for quiet operation. It has one on/off switch for the engine and the fuel valve, for ease of use.

1

Engine

The Honda EX650 runs on a 76cc four-stroke side-valve single-cylinder engine. Its compression ratio is 6:1, and it runs at a speed of 3,600 revolutions per minute (RPM). It has a forced air-cooling system and a Transistor Magneto ignition. Its oil tank has a capacity of 0.37 quarts, and its fuel tank has a capacity of 0.53 gallons. It has a recoil starting system. Measured in horsepower, its engine has a power output of 1.6 HP.

  • The Honda EX650 runs on a 76cc four-stroke side-valve single-cylinder engine.
  • Its compression ratio is 6:1, and it runs at a speed of 3,600 revolutions per minute (RPM).
2

Power

The maximum power output of the EX650 is 650 watts. Running on alternating current (AC) power, it is rated for a voltage of 120 volts at a frequency of 60 Hz, ampere of 4.6 amps, and a constant power output of 550 watts. It should only be run on direct current (DC) power to charge 12-volt automotive batteries, and its maximum charging output is 8.3 amps.

3

Other Specifications

Under normal operating conditions, the EX650 can operate for approximately 3.8 hours on one tankful of gasoline and oil. It runs at a noise level of 54 decibels. Overall, the EX650 measures 17 by 10.6 by 14.8 inches, and it weighs 23.1 Kilogram. It has a United States Department of Agriculture (USDA) certified spark arrester and muffler.

  • Under normal operating conditions, the EX650 can operate for approximately 3.8 hours on one tankful of gasoline and oil.
