Graphing Calculator Art: How to Make a Face
A simple smiley face is made of circles. (Jupiterimages/Photos.com/Getty Images)

Though a graphing calculator is capable of advanced mathematical computations and statistical data analysis, students mainly use these devices to draw the graphs of functions. A graphing calculator can plot the curves of several equations in a single viewing window, making it possible to draw recognisable pictures. You can input the equations of several semicircles to make a smiley face on your calculator's graphing window.

Skill level:
Moderate

Other People Are Reading

Instructions

  1. 1

    Press the "Y=" key to access the function input menu. This is where you will type the circle equations to make the smiley face on your graphing calculator.

  2. 2

    Enter the equation "sqrt(100-x^2)" in the field labelled "Y1" and the equation "-sqrt(100-x^2)" in the field labelled "Y2." These are equations for semicircles with a radius of 10 and together they form the border of the face. The first equation generates the top half of the circle while the second generates the bottom half.

  3. 3

    Enter "-sqrt(49-x^2)" in the field marked "Y3." This semicircle forms the smiling mouth.

  4. 4

    Enter the equations "3+sqrt(4-(x-4)^2)" and "3-sqrt(4-(x-4)^2)" in the fields labelled "Y4" and "Y5." This forms the right eye.

  5. 5

    Enter the equations "3+sqrt(4-(x+4)^2)" and "3-sqrt(4-(x+4)^2)" in the fields labelled "Y6" and "Y7." This forms the left eye.

  6. 6

    Press the "Zoom" key and select "Zoom Square" from the drop-down menu. This removes the scaling distortion from the viewing window.

  7. 7

    Press the "Window" key, highlight "Format" and select the "Axes Off" option. This removes the x and y axes from the graphing window so that your smiley face is unobstructed.
