How to make a cardboard cylinder
Cardboard tube (cardboard spool of pink thread isolated on white image by Olga Sapegina from Fotolia.com)

Cardboard cylinders can be used in everything from making models to creating toys. Larger and thicker cylinders are used to ship documents and to protect fragile objects from damage. Making cardboard cylinders is easy and worthwhile for special sizes or shapes that are not readily available.

Skill level:
Moderately Easy

Other People Are Reading

Things you need

  • Chipboard
  • Ruler
  • Scissors
  • Paper clamps
  • Paper tape
  • Rubber bands
  • 3M spray adhesive

Show MoreHide

Instructions

  1. 1

    Purchase a long sheet of chipboard. Chipboard is a thin type of cardboard that is often found on the backs of notebooks. Paper Source stores sell the chipboard in large sizes up to 48 inches long.

  2. 2

    Cut two pieces of chipboard into two rectangles with scissors. The short side of each rectangle should be the same as the length of the cylinder. For this example cut the length 3 times the length of the short side.

  3. 3

    Measure the top of each chipboard at 1/2 its length and mark this spot as A. Mark the top right corner as B.

  4. 4

    Mark the bottom left corner as C. Measure the bottom of each chipboard at 1/2 its length and mark this spot as D.

  5. 5

    Draw a line between A and C. Cut along this line. Draw a line between D and B. Cut along this line.

  6. 6

    Take corner B of one chipboard and curl it under toward the left until B touches D. Use a paper clamp to clamp these two points together. Take corner C of the same chipboard and curl it under and toward the right until C touches A. Use a paper clamp to clamp these two points together.

  7. 7

    Moisten brown paper tape with water and tape along the seam where the cylinder touches. Use rubber bands to help the cylinder hold its shape while the paper tape cures. Allow the tape to dry for one hour.

  8. 8

    Remove the clamps and spray the outside of the cylinder with 3M spray adhesive. Glue your second piece of cut chipboard over the first chipboard with the seams opposite. This will strengthen the cylinder.

  9. 9

    Cut paper tape longer than the length of the cylinder seam. Moisten and place your tape so that you can tuck each end inside the cylinder. Use rubber bands over the tape to hold the tape and the chipboard in place while both dry.

Tips and warnings

  • If you add many layers for a thick cylinder you will need to make outer layers slightly longer to accommodate the depth of the chipboard.
