What are the Types of Milling Cutters?

Written by casandra maier
  • Share
  • Tweet
  • Share
  • Pin
  • Email
What are the Types of Milling Cutters?
Milling cutters are used on vertical and horizontal milling machines. (milling machine image by Andris Daugovich from Fotolia.com)

Normally made of high-speed steel, milling cutters are the interchangeable blades of a milling machine. Milling is defined as, "the process of machining flat, curved, or irregular surfaces by feeding the workpiece against a rotating cutter containing a number of cutting edges," according to Metal Web News. The teeth provide fast and efficient cutting. There are 13 different types of milling cutters, available in many widths, angles and diameters.

Other People Are Reading

End Mill

End mills are one of the 13 different types of milling cutters, and the most commonly used. End mills are generally used in a vertical milling machine. The teeth are powerful enough to drill their own starting holes. End milling cutters stay true to their name, with teeth on the end, and generally along one side.

What are the Types of Milling Cutters?
An end mill looks similar to a drill bit. (drill bit image by Greg Pickens from Fotolia.com)

Slot Drill

Similar to an end mill, a slot drill is used when an end mill cannot complete the job. They are distinguished by two fluted cutters and a single tooth. Slot drills are used for cutting keyway slots. Cutting directly into the material, a slot drill uses its teeth to break through work material.

What are the Types of Milling Cutters?
Slot drills are used for cutting keyway slots. (keys in lock image by willem169 from Fotolia.com)

Roughing End Mill

You would use a roughing end mill if you needed to cut out large chunks in wavy patterns. A roughing end milling cutter leaves a rough surface behind. Also referred to as ripping cutters, a roughing end mill is recognised by its wavy teeth. Roughing end mills are known for quieter cutting, as their wavy teeth minimise vibrations.

What are the Types of Milling Cutters?
Roughing end mills leave behind a rough finish. (Oak Wood Grain Detail Close Up image by James Phelps from Fotolia.com)

Involute Gear Cutter

Involute gear cutters are available in eight different sizes. These milling cutters come in circular form. They are distinguished by 12 cutting teeth organised around its circumference.As with all milling cutters, there are a variety of diameters to choose, making involute gear cutters a very versatile cutting tool.

What are the Types of Milling Cutters?
Involute gear cutters are round like a saw blade. (cutter circle image by Vaida from Fotolia.com)

Slab Mill

Slab mills create wide cuts. The cylindrical shape cuts horizontal surfaces. Made from high-speed steel, the teeth of a slab mill are at a helix angle. The helix angle allows the teeth to engage slowly, distributing force. Slab mills cut on a periphery and are used on horizontal milling machines.

What are the Types of Milling Cutters?
Slab mills cut along the periphery of a horizontal surface. (wood image by Ekaterina Shvigert from Fotolia.com)
