If you want to create a new Basic Input/Output System (BIOS) password on a Dell Optiplex 745, reset the password. Resetting the password also applies if you want to remove an existing BIOS password. BIOS passwords are used to add an additional level of security to your machine. Without the correct BIOS password, your Dell Optiplex 745 will not complete the boot process. The password can be reset whether you know your current password or not.
Turn off your Dell Optiplex 745.
Start the computer.
Press "F2" the moment the Dell logo appears on the screen. You will only have two to three seconds to press the key.
Enter your BIOS password.
Navigate to the "Exit" screen.
Select the "BIOS Password" setting.
Enter your BIOS password and a new password if desired. Do not enter anything in the "New Password" box if you want to remove the BIOS password completely.
Press "Enter" to save your password settings.
Turn off your Dell Optiplex 745 and remove the power cord from the computer.
Disconnect any external hardware and cables.
Slide the release latch located on the back of your Optiplex 745.
Lift the cover as you slide the latch.
Hold the cover firmly and pivot it back on the hinges.
Remove the cover from the hinges.
Find the "PSWD" jumper on the motherboard. This is a two-pin jumper and should be clearly labelled. Use a flashlight and magnifying glass if you have trouble locating it.
Remove the jumper from the motherboard.
Replace the cover and slide it into place until the latch snaps into place.
Reconnect the power cable and restart your computer.
Shut down the computer after it has completely restarted.
Disconnect all cables and remove the cover again.
Replace the PSWD jumper.
Replace the cover.
Reconnect all cables and restart your computer.
Never make contact with carpeting when working on your computer. This can generate static electricity that will damage the machine.
Tips and warnings
- Never make contact with carpeting when working on your computer. This can generate static electricity that will damage the machine.
Things you need
- Flat-blade screwdriver
- Philips screwdriver
